Hadco DB30 LED Lighting Bollard
Description
Description
The DB Series is a line voltage Bollard available in incandescent, CFL, HID and LED sources. This versatile luminaire features a dome roof with die-cast aluminum louvers, and in a variety of heights. Optics include a symmetric, die-cast aluminum louvers with underside painted with highly reflective white powdercoat and a tempered glass globe. The LED sources features a 9.5W Philips LED EnduraLED lamp, LED 4Kv medium base porcelain socket A19. The 2700K warm white delivers 800 lumens and the lamp life is rated at 25,000 hours.
HOUSING:
360 low-copper die-cast aluminumalloy. Dome roof with die-cast aluminum louvers. Easy access to lamp. 5a dia. extruded aluminum with a wall thickness of 0.125a. All non-ferrous fasteners prevent corrosion and ensure longer life.
FINISH: Thermoset polyester powder coat is electrostatically applied after a five-stage conversion cleaning process and bonded by heat fusion thermosetting Laboratory tested for superior weatherability and fade resistance in accordance with ASTMB117 specifications. For larger projects where a custom color is required, contact the factory formore information.
OPTICAL ASSEMBLY:
Symmetric.Die-cast aluminum louvers with underside painted with highly reflective white powdercoat. Tempered glass globe.
LAMPING:
9.5W Philips LED EnduraLED lamp, LED 4Kv medium base porcelain socket A19. 2700K warm white delivers 800 lumens. Lamp life is rated at 25,000 hours. 120 volt only.
ELECTRICAL ASSEMBLY:
Ballast assembly is mounted to an aluminum plate, which is mounted inside the base. Quick disconnects for easy installation and removal.
INSTALLATION & MOUNTING:
Tube is mounted to the baseplate with three (3 )5/16-18 flathead allen key stainless steel tamper-resistant screws.
WARRANTY:
Five-year limited warranty.
CERTIFICATIONS:
ETL listed to U.S. safety standards for wet locations. cETL listed to Canadian safety standards for wet locations.Manufactured to ISO9001:2008 Standards.
Height: 313/4"(80.65cm) Width:6"(15cm)
BoltCircle:3"(8cm)
Anchor Rods:
Internal (3) 3/8"dia. x 8"long (1cmx20cm)
BaseDiameter: 5"(13cm)
Max. Weight:
Powdercoat: 15 lbs
